Headlight switch help

Brando5641

New Member
Jul 21, 2009
127
0
0
FT Gibson OK.
I need a wiring diagram to tell me what wires go where on the switch its self. my plug has had some of the wires pulled out and a few cut ones around it and i need somthin to go off of. I spent an hour looking on google but nothing.

1986 mustang lx v8 5 speed

http://www.youtube.com/watch?v=1JsF7KEV8uQ

http://www.youtube.com/watch?v=1JsF7KEV8uQ <<<<<< this one has what order the wires were in on the plug.

The pug with all the slpices on it whent on the middle prong.
I show to have 12v to all of them except the small tan wire that is some how running all of the lights when i touch it to 12v.

Also will the car not turnover when the colum is droped? I put the key in it to test some other stuff and it wont turn over now???

  • Sponsors (?)


See http://www.stangnet.com/mustang-forums/789403-86-fuse-eletrical-problem.html to get info on how to download the whole manual

The following link should do it.
http://slantnosefox.com/picturehosting/jeremy/86 electrical & vacuum troubleshooting manual.zip

You'll need WinZip or similar archice tool to unpack it. See MajorGeeks.com - Download Freeware and Shareware Computer Utilities. for WinZip.

attachment.php


Attachments

  • 79.jpg
    76.6 KB · Views: 1,294
