I will run my car for half an hour and this causes the starter solenoid to heat up and then the car will not start until its cooled down ,,,, I don't know what to do …. Any help would be great . I have already replaced it once and it still happens ,
No Crank checklist for 5.0 MustangsI will run my car for half an hour and this causes the starter solenoid to heat up and then the car will not start until its cooled down ,,,, I don't know what to do …. Any help would be great . I have already replaced it once and it still happens ,
Do you have no crank or cranks OK but the engine will not fire off and run condition?Thanks for the info , I am leaning towards the TFI module , did a bunch of wire tests and all seem ok , will update soon
After driving for 30 min or so and turn off car ,, if I try to start it it attempts to roll over but then quickly dies off and will not do anything until it cools off .. like 20 min wait and then will have a slow turn over and fire up and run normal againDo you have no crank or cranks OK but the engine will not fire off and run condition?
I have a new battery installed and a new solenoid on the fender well ... seems like the TFI might be the. Culprit for only 75$ I think I’ll try it and see what happens .,this is my 5th foxbody 5.0 and never had this issue beforeD
No Crank checklist for 5.0 Mustangs
Revised 24 May 2018 to add check for backup lights harness as a no crank problem.
No crank, slow crank and stuck starter solenoid problems have the same root causes – low battery voltage and poor connections. For that reason, they are grouped together.
Use the same initial group of tests to find the root cause of slow crank, no crank and stuck solenoid problems.
Since some of the tests will bypass the safety interlocks, make sure that the car is in neutral and the parking brake is set. Becoming a pancake isn’t part of the repair process…
1.) Will the car start if it is jumped? Then clean battery terminals and check battery for low charge and dead cells. A good battery will measure 12-13 volts at full charge with the ignition switch in the Run position but without the engine running.
A voltmeter placed across the battery terminals should show a minimum of 9.5-10 volts when the ignition switch is turned to the Start position and the starter engages or tries to engage. Less than this will result in a clicking solenoid, or slow cranking (if it cranks at all) or a starter solenoid that sticks and welds the contacts together.
Most auto parts stores will check your battery for free. It does not have to be installed in the car to have it checked; you can carry it with you to the auto parts store.
The battery posts and inside of the battery post terminals should be scraped clean with a knife or battery post cleaner tool. This little trick will fix a surprising number of no start problems.
The clamp on with 2 bolts battery terminal ends are a known problem causer. Any place you see green on a copper wire is corrosion. Corrosion gets in the clamped joint and works its way up the wire under the insulation. Corroded connections do not conduct electricity well. Avoid them like the plague...
If the starter solenoid welds the contacts, then the starter will attempt to run anytime there is power in the battery. The cables and solenoid will get very hot, and may even start smoking. The temporary fix for a welded starter solenoid is to disconnect the battery and smack the back of the solenoid housing a sharp blow with a hammer. This may cause the contacts to unstick and work normally for a while.
A voltmeter is handy if you are familiar with how to use it to find bad connections. Measure the voltage drop across a connection while trying to start the car: more than .25 volts across a connection indicates a problem. The voltage drop tests need to be done while cranking the engine. It's the current flowing through a connection or wire that causes the voltage drop.
See http://assets.fluke.com/appnotes/automotive/beatbook.pdf for help for help troubleshooting voltage drops across connections and components. .
Voltage drops should not exceed the following:
200 mV Wire or cable
300 mV Switch or solenoid
100 mV Ground
0.0V Connections
A voltage drop lower that spec is always acceptable.
2.) Check the battery to engine block ground down near the oil filter, and the ground behind the engine to the firewall. All grounds should be clean and shiny. Use some sandpaper to clean them up.
3.) Jump the big terminals on the starter solenoid next to the battery with a screwdriver - watch out for the sparks! If the engine cranks, the starter and power wiring is good. The starter relay is also known as a starter solenoid.
The rest of the tech note only concerns no crank problems. If your problem was a stuck solenoid, go back to step 1.
4.) Then pull the small push on connector (small red/blue wire) off the starter solenoid (Looks like it is stuck on a screw). Then jump between the screw and the terminal that is connected to the battery. If it cranks, the relay is good and your problem is in the rest of the circuit.
5.) Remember to check the ignition switch, neutral safety switch on auto trans and the clutch safety switch on manual trans cars. If they are good, then you have wiring problems.
Typical start circuit...
Diagram courtesy of Tmoss & Stang&2birds
6.) Pull the starter and take it to AutoZone or Pep Boys and have them test it. Starter fails test, then replace it. If you got this far, the starter is probably bad.
Starter solenoid wiring for 86-91 Mustang
Starter solenoid wiring 92-93 Mustang or earlier Mustang with upgraded high torque mini starter.
Electrical checks for the switches and starter solenoid
Remove the small red/blue wire from the starter solenoid. Use a screwdriver to bridge the connection from the battery positive connection on the starter solenoid to the small screw where the red/blue wire was connected. The starter should crank the engine. If it does not, the starter solenoid is defective or the battery lacks sufficient charge to crank the engine.
If the starter does crank the engine, the problem is in the clutch safety circuit (5 speed) or Neutral Sense Switch (auto trans) or ignition switch.
See the Typical start circuit diagram above for wiring information for troubleshooting.
You will need a voltmeter or test lamp for the rest of the checks. Connect one lead of the voltmeter or test lamp to ground. The other lead will connect to the item under test.
Look for 12 volts on the white/pink wire when the ignition switch is turned to the Start position. Check the ignition switch first.
No 12 volts, replace the ignition switch.
The next step will require you to push the clutch pedal to the floor (5 speed) or put the transmission in neutral (auto trans) while the ignition switch is turned to the Start position.
Good 12 volts, check the clutch safety switch (5 speed) or Neutral Sense Switch (auto trans) for good 12 volts on both sides of the switches. No 12 volts on both sides of the switch and the switches are defective or out of adjustment. Check the wiring for bad connections while you are at it.
The next check is courtesy of Killing Hours.
For manual shift transmissions only: check to see that the backup light switch harness is intact and in good condition. There is a wire in the harness that loops 2 pins coming from the body side of the harness. This is the bypass for the auto transmission Neutral Safety Switch. If the connector is damaged, oil soaked or missing you will have a no crank condition.
Backup lights harness for 5 Speed transmission showing the bypass loop for the Auto Trans NSS
Courtesy of Killing Hours
Me too. New battery, cables, solenoid, cleaned all grounds. I haven’t had a problem since either.Do the ole voltage drop test on your battery cables, make sure your grounds are good, also the battery too, bad connections and low voltage causes the wires to heat up and makes the connections worse. Also it's hard on the starter which likely needs tested too, I just went through this and I replaced my starter and battery cables, no more problems.
You are saying that the starter will not crank the engine when it gets hot?After driving for 30 min or so and turn off car ,, if I try to start it it attempts to roll over but then quickly dies off and will not do anything until it cools off .. like 20 min wait and then will have a slow turn over and fire up and run normal again
You are using terms that no one is clear on what you mean: "roll over", "dies off", "turn over", "fire up",After driving for 30 min or so and turn off car ,, if I try to start it it attempts to roll over but then quickly dies off and will not do anything until it cools off .. like 20 min wait and then will have a slow turn over and fire up and run normal again
I have a new battery installed and a new solenoid on the fender well ... seems like the TFI might be the. Culprit for only 75$ I think I’ll try it and see what happens .,this is my 5th foxbody 5.0 and never had this issue before
Slow ...if at all for a small window then nothing ..wait 20 mins then the car starts as nothing was wrongOk, lets help you by asking some mechanical themed questions:
Is the engine spinning over fast or slow when hot
What is your timing set at
You are using terms that no one is clear on what you mean: "roll over", "dies off", "turn over", "fire up",
Yes exactly ,, the starter won’t crank the engine over when hot .. cars sits for 20 minutes then it will start upYou are saying that the starter will not crank the engine when it gets hot?
The terms are called cranking, starting, running.
You've had 5 of these cars & never heard of these?
Doesn't sound like TFI to me. Instead of throwing good money away, send it to me.
SlowOk, lets help you by asking some mechanical themed questions:
Is the engine spinning over fast or slow when hot
What is your timing set at
