Accessory and bracket pics PLEASE!

[bobbys9350]

OK guys, i got my new shortblock in and everything pretty much done. now all thats left to do is bolt all the brackets and accessories back up along with putting on the water pump. well guess what...... i didnt pay much attention when taking this stuff off!! I really need pics of the accessories and brackets up close so i know how everything goes back together. I have all factory accessories in original location. If you guys could post some pics or have a diagram that would be soo helpful! thanks a lot! :SNSign:



[stang8urimport]

bracket:

Accessories:



[bynummustang]

I don't get the guitar pic?



[wythors]

I don't get the guitar pic?

"Accessories"

This may help. I took this to help me remember where everything went when I did my h/c/i project a few weeks back.

View attachment 437747



[85_SS_302_Coupe]

Just remember it only works one way....keep foolin with it untill you figure it out. Try putting on the power steering relocater bracket without instructions...that's a tough one.



[bobbys9350]

Poopdawg...... HAHAHHA! thats some funny stuff!

Wythors.... that pic helps a lot, i really appreciate it! i would love to see some more pics of everything bolted up if anyone has them still, thanks a lot guys!!!



[superhuaman]

do these help? theyre not exactly close up on the accessories...



[notch22]

I need this also. Doing the 2.3 to 5.0 swap, no idea how all this stuff goes on.....



[85_SS_302_Coupe]

Ok guys this is about as good as it's gonna get....this is a really old shot from the last time i remember someone asking this question and i took a picture for that thread (history definately repeats itself in the forum world lol).

On the aluminum part, there's a fat end that you can see in this pic....flip it around untill it looks like it does in this pic and the bolts should line up...after that do the same with the metal plate. The straight yellow lines represent the bolts for the PS pump. Once you get it you'll smack yourself for not seeing it.

Hope that helps.



[JimBowy]

ya, good luck....



[wythors]

What the deuce?

That's freakin' wild!



[superhuaman]

crap, man



[DMAN302]

That's just a huge amount of work...yeah....



[JimBowy]

That's just a huge amount of work...yeah....

ya, when the whole thing becomes custom, life becomes more exciting



[notch22]

Yeah I am trying to stay with the good ole stock ones. No welder here, I could get creative if i did.
