EGR Simulator

[94TURBO5 O]

Anyone tried one of these before?

http://cgi.ebay.com/ebaymotors/ws/e...d=1,1&item=7985385155&sspagename=STRK:MEWA:IT

Looks interesting and may help you guys get rid of the CE light. I know most people just use the stock piece but this also looks cooloer.
I think I might try one and throw away my stock one.



[DFG 5OH]

nice find JR. I thought there was a way to trick the comp into thinking that the EGR was still there without buying anything



[Dan95-5.0]

i've read people using that and still not have the CE light come off.

i used the Rio5.0 method and it works flawlessly. didnt even have to adjust it and its tucked away behind the valve cover and under the intake so its out of the way and barely visible.



[Labora]

Haha 25$ and you are basically getting a resistor and some shiny new plastic parts. I'll pass and just leave the plunger pushed half way down.



[urban96]

plunger 1/2 way in works great



[DFG 5OH]

anyone got a write up on how to delete the EGR and not get the CEL light?



[95Mustang302]

anyone got a write up on how to delete the EGR and not get the CEL light?

what he said!

also is it a bad idea to remove it???



[94gts]

I think I might try one and throw away my stock one.

let us know how it works!



[Labora]

You do know you can go to radio shack and get the right size resistor to disable the EGR for less then 2$ right? Or you just like buying something with huge markup???



[94GTLaserRC]

I just use the TwEECer

RC



[94-302-vert]

EGR Delete:

1. Mechanical:- Buy/Make a block off plate for the intake manfold. Unbolt the EGR and put this in it's place. Remove the tube from the exhaust header and cap it with a 3/4" (could be a 5/8") cap from Lowed/HD/ etc.

I jsut took a piece of metal shim stock and placed it between the EGR and the intake manifold leaving all the plumbing in place.

2. Electrical:- Remove the 3 bolts holding the EGR controller (or whatever it is called) from the actual EGR (the grey thing from the metal thing). then you will see the plunger (metal rod that moves fairly easily). Figure out a way to hold that somewhere in the middle of it's travel. I used a yellow wire nut that I pressed on with a vise then put a small hose clamp to help hold it in place. Re-attach to the wiring and hide it in the engine compartment.

Done.



[DFG 5OH]

thanks chris



[hiattwl]

I feel like a dumbass after i bought that simulator. I didn't wanna have the plunger still under the hood, and i used that, still had a CEL, and then the damn thing fell off a week later and i havn't seen it since.

What a waste of money, this weekend i'm going to do the plunger thing, i've been away from home for 3 weeks and the baby needs some work.

Wayne



[94TURBO5 O]

F-It thanks for the helpful replies. I'm not going to waste my $$. Glad I posted up to ask about this.



[tmoss]

Make your own............



[18mustangs]

I just use the TwEECer

RC

The only real way to delete the EGR! Otherwise your'e just running lean at part throttle.



[CManT1914]

I feel like a dumbass after i bought that simulator. I didn't wanna have the plunger still under the hood, and i used that, still had a CEL, and then the damn thing fell off a week later and i havn't seen it since.

What a waste of money, this weekend i'm going to do the plunger thing, i've been away from home for 3 weeks and the baby needs some work.

Wayne
