Electrical question (Burnt airbag module 94 cobra)

[Mstng93SSP]

OK, let me start by saying electrical is NOT MY THING....AT ALL. Anyway, The airbag module (blue one under the stereo in my 94 cobra) fried. It smells burnt. I took it out, and pulled the top blue plastic off and I can see the one of the parts is burnt. Through research I see that it is Metal Oxide Varistor MOV40? Whatever that is...So, here is my questions. I was blowing fuse #4 (airbag module fuse 10 amp) every time I would put one in. It seems that this module was the culprit, but to verify if I put a fuse in the #4 slot without the module being plugged in, if there was a wiring problem prior to where it plugs into the module would the fuse blow? And if it doesn't blow can I safely figure that the module itself is what was causing the fuse to blow?



[Davedacarpainter]

Uhmmmmm........

That’s all I got Chris........if you need anything else, just.....Uhm......



[General karthief]

Whenever your messing with the air bag wiring stay clear of the bags just in case. Disconnect the battery and use a jump wire connected to the plug for the module and see if power is at your fuse, if you know how to use a multimeter you can check continuity but I get confused sometime using one, I would say that module is bad, obviously.



[Mstng93SSP]

OK. Thanks



[Davedacarpainter]

OK. Thanks

Anytime Chris, I’m here to help



[Mstng93SSP]

I'm gonna just see if it blows up.....



[Mstng93SSP]

Ok, happy to say airbags are still intact. I did some testing and it is just the module that is bad. I have a other one (go figure right?) but didn't want to install it until I knew there wasn't a bigger problem. All is good, no more inbound missile alerts blinking in my cluster.
