Need some pics from a 94-95 owner - rear axle brake line routing

[Mustang5L5]

Can someone with a 94-95 snap some pics for me? I'm putting cobra brakes on my Fox and not happy with the way the hard line came out. The loop is too big. Can someone photograph how their line is and also see if you can get a shot of the outer axle bumps so i can see how much room I have to work with in the area? Thanks!



[Venom351R]

If no one else gets to it before me I'll go out and take some pics today, I'll be doing some dubbing around in the garage later today anyway so if no one else has posted up any pics yet I'll get some.



[Mustang5L5]

K thanks!



[Venom351R]

Here is the best I can get w/ the axle on the car and the quad shocks on. Hope it helps some.



[Mustang5L5]

Yes, that's exactly what I needed to see! Thanks!



[Venom351R]

Great! No prob at all, now I need to go put my wheel back on



[BlownFiveLiter]

If you need some more pics, I'm probably gonna go out in the garage and work on mine a little bit. I can crawl underneath and grab some more, since it's sitting on stands right now. Just let me know...
