Hey all - Recently picked up a 1989 GT, 5 speed and struggling with some electrical challenges.
Issue # 1: My ignition wire (pink/white) has been very poorly converted to a yellow wire, which now goes straight down to the neutral safety switch, which I found unplugged. When it gets there, it is just shoved into the back of the connector and pops out quite easily. Guessing this was done by previous owner as some sort of bypass because I don’t need to push the clutch to start.
From the diagrams, it looks like the wire is supposed to go to the switch, but not sure where it should actually be connected as the rest of the wires appear to be correct. I would like to get it to the right place and connected correctly, and also plug the connector into the clutch safety like it should be. Included pictures of the connection and the empty plug space/other connector for reference.
View attachment 712729 View attachment 712730 View attachment 712731
Issue #2: Reverse lights don’t work. Rest of tails and functionality are good. Checked bulbs, changed switch on transmission, changed harness to the switch, checked fuse, all looks good. Anything else obvious to check before I break out the meter?
Issue #3: high beam indicator stays on all the time. Prior owner changed headlights to some odd LED ones. Based on research, I was able to switch some of the wires in the hi/lo/flash to pass, so they actually function correctly with the stick and all the beams are working properly. Only issue is the indicator is always lit. Research suggests possible grounding issue or perhaps dimmer switch, anything else to be checking that may cause the issue?
Sorry for the long post, electrical isn’t really my forte and I’m learning a lot of this as I go. Tried to do as much research as possible but I’m a bit stuck on some of these. Any recommendations are appreciated!!
